Feature：
100mm voice coil, high transient response woofer
Phase-inverted Enclosure design
Humanized built-in handle for transportation and installation
Extended full range speaker low-frequency response
Thick & elastic hearing
Application:
Bar
Multi-function hall
Church
Theatre
Structure and Size
Frequency Response Curve
Impedance Curve
| Technical specification： | |
| Frequency response： | 30Hz~200Hz(±3db) 25Hz~250Hz(-10db) |
| Average sensitivity(1w/1m)： | 99dB |
| Power handling(AES/PEAK)： | 800W/3200W |
| Nominal impedance： | 8Ω |
| Maximum SPL(AES/PEAK)： | 128dB/134dB |
| LF driver： | 1 × 18″ driver(4″ voice coil) |
| Physical data： | |
| Cabinet size(H×W×D)： | 698×552×700mm |
| N.W： | 44kg |
| Connectors： | 2 × 4-pin Speakon NL4 |
| Material： | 18mm and 25mm birch plywood |
| Finish： | black stonetex paint |
| Grille： | steel mesh |
| Handle： | 4 |
